AVIOR-24S ™ CHAPTER II
Hardware Integration
41
NAVIOR-24S ™ Revision V1.00 20.05.2008
Mounting
The NAVIOR-24S GPS/GLONASS PCB is RF section, encased in a metal enclosure. The
enclosure acts as a protective case of RF section.
The NAVIOR-24S GPS/GLONASS module can be attached to the integrator platform using
Surface-Mount Mating Connector. Recommended surface mount mating connector is Samtec’s part
number
TFM-110-xx-S-D, when xx – Lead Style
connector must be attached to the NAVIOR-24S GPS/GLONASS module prior to securing the
module to the user’s PCB.
Note – See Appendix E for mechanical drawings and specifications regarding the spacing of the
mounting tabs and the dimensions of the enclosure.
