AVIOR-24S ™ CHAPTER 1

Starter Kit

NAVIOR-24S ™ Revision V1.00 20.05.2008

Starter Kit

The Starter Kit makes it simple to evaluate the NAVIOR-24S GPS/GLONASS receiver’s

exceptional performance. The Starter Kit can be used as a platform for configuring the receiver

module and as a platform for troubleshooting your design. The Starter Kit includes:

• NAVIOR-24S GPS/GLONASS module mounted on an interface motherboard in a durable

metal enclosure. The motherboard accepts (7-15) VDC power and provides regulated +3.3V

power to NAVIOR-24S GPS/GLONASS receiver and antenna amplifier. The motherboard

also contains:

- 3.0 V lithium battery that provides back-up power to the receiver

- Circuitry to convert the CMOS output to RS-232, enabling the user to connect the

RS-232 ports in the Starter Kit to the PC COM port via RS-232 cable connection.

- Circuitry to convert the CMOS output to RS-485 for 1PPS

• GPS/GLONASS Antenna

• 10 meter RF cable

• Two 9-pin RS-232 interface cables (DB-9F/DB-9M)

• AC/DC power supply adapter (input: 240V AC output: 9V DC)

• CD containing software tools used to communicate with the receiver, the System Designer

Reference Manual.
