The channels info table contains the following information:
o SNS SNS the SV belongs to.
o SVn/Fn SV number for GPS SV and frequency number for GLONASS SV.
o SNR Signal Noise Ratio
o Mode Tracking mode
auto Automatic tracking
manual This channel was manually set to track this satellite.
test Test mode during the receiver test.
fault Broken channel.
o Status A bit mask of measurements status. See table below.
o PR Pseudo range modulo 1 msec.
o PD Pseudo Doppler
Table IV-5 - The status bit mask is composed of the following bits.
Bit# Meaning
0 Non-zero SNR.
1 Pseudo range and pseudo Doppler are measured
2 Smoothed range is measured
3 Pseudo phase is measured
4 Time synchronization
5 reserved
6 reserved
7 reserved
8 Ephemeris data are available
9 Almanac data are available
10 reserved
11 GLONASS-M satellite
12 Measurements are ready to be used in solution
13 Measurement have been used in solution
14 reserved
15 Measurements are RAIM-discarded
