N
AVIOR-24S ™ Appendix E
N
MEA Tool kit User’s Guide
203
NAVIOR-24S ™ Revision V1.00 20.05.2008
Interface overview
The Main Window contains for group boxes. They are: COM PORT, TRANSMIT TYPE, FILE,
ADD:
1) You can select data source for STOREGIS in the COM PORT goupbox using:
- available data source pulldown menu.Options are: FILE (for a file) and COMxx
(COM- ports, available on this PC);
- baud rate pulldown menu;
- SYNCHRO – synchronize baud rate button;
- «-/+» - file processing speed control buttons;
- Pause – pause file processing.
If FILE option is selected for a data source, the SYNCHRO button is replaced by the «-\+» and
Pause buttons;
2) You can data format in the TRANSMIT TYPE group box:
- NMEA – data are NMEA sentences;
The START/STOP button starts/stops data processing.
Note – NMEA is the only available data format now.
3) The FILE groupbox contains information about the size of processed data in kB, port errors (Port
err)
and protocol errors (Prot err). You can specify a name for an input/output file by clicking the
button with a filename (defaults to “rgfile”) on it;
4) The ADD goupbox contains checkboxes which activate additional windows:
- Position – the POSITION window (sec.3.3)– current position information;
- Statistic – the STATISTIC window (sec.3.4)– position statistics;
- Kinematic – the KINEMATIC window (sec.3.5)– speed and heading information;
- Visual – the VISUAL window (sec.3.6)– position graphical chart;
- Profile – the PROFILE window(sec.3.7)– height profile.
The Main Window titlebar displays information about a receiver STOREGIS is connected to.
STOREGIS progress messages are also displayed in the titlebar.
