NCR 7169 Multifunction Printer 1-45
Using the Printer
To use the printer, follow these steps:
1. Connect the power supply to the printer and turn on the power source. The printer
goes through a self–test routine to ensure everything is working properly, and then
it beeps. After the printer has completed its startup cycle, it is ready to receive data.
If the LED blinks or the host computer indicates that there is a problem, refer to
Troubleshooting Problems on page64 for more information.
2. To perform a Configuration check (optional), reset the printer while holding the
Paper Feed button, or open the receipt door and, while pressing the Paper Feed
button, close the receipt door. Let go of the Paper Feed button when the printing
begins.
Note: The printer receives power when the power supply is on even if the printer is
offline. To completely remove power, unplug the power supply from the outlet, or turn
the POS terminal off.
