2.11 Mounting the Option Board
The following option board or multimedia switcher (MM3000B) can be mounted to the slot A and
B of the projector.
Name Slot A Slot B
Image Media Block NC-80MB01 * *
NC-80LB01 * * Signal Input Board
NC-80DS01 * *
Multi-media Switcher
MM3000B * -
This section describes the procedure of mouting the media block and signal input board. For the
procedure of mouting multi-media switcher, refer to “MM3000B Installation Manual”.
Preparatory operation:
Phillips head screwdriver (No.2) and cover key (attached goods).
- Step 1
Remove the Projector Cover (See page 101)
- Step 2
Mount the Opti
on Board to the Projector (See page 101)
- Step 3
Mount the Cover to the Projector (S
ee page 102)
- Step 4
R
ecovering from Tamper Errors (See page 106)
Setti
ng up the Projector (See page 103)
Note
If you remove the front cover, side cover, or lens side cover, the following error message is
displayed on the LCD screen of the main unit operating panel by the tamper detection circuit.
“Tamper Fail”, “Service Door Open”
Also, if you remove the closing panel or device from slot, the following error message is
displayed on the LCD screen of the main unit operating panel by the tamper detection circuit.
Furthermore, since the marriage is cleared, re-marriage is necessary.
“Marriage Tamper Fail”, “Physical Marriage Tamper”, “Marriage Not Active”
Encrypted contents cannot be displayed while an error message is being displayed. Refer to
“3.2 Recovering from Tamper Errors” (page 106) for the recovery procedure.
