3. Projector Adjustment and Connection
127
3.9 Connecting with the Image Input Port
By installing option board to projector, you can add input port. The following shows the input
port, which can add to each option board.
NC3200S-A/NC3240S-A Option board is not installed at factory default.
NC3200S An NC-80LB01 is installed to slot B at factory default.
(slot A is empty)
Input port which can add to option board is listed below. For the connection diagram of projector
and peripheral equipment, refer to Installation manual of option board. Refer to projector’s
manual when using NC3200S.
Option Board Image Input Port
NC-80LB01/NC-80DS01 (Note1) HD-SDI input port (BNC)x4
DVI-D input port (DVI-D 24pin)x2
NC-80MB01 Storage port (for connection to NC-80SS01)
MM-70DV01 DVI-D input port (DVI-D 24pin, HDCP support)
MM-RGB-E RGB input port (BNC5 conductors)
MM-SDI-E SDI input port (BNC)x2
Monitor input port (BNC)
MM3000B
(Note2)
MM-VIDEO-E CVBS input port (BNC)
S-Video image input port (BNC2 conductors)
Component video input port (BNC3 conductors)
Note1: NC-80LB01 supports CineLink 2, and NC-80DS01 does not support CineLink 2.
NC-80DS01 cannot display the encrypted contents.
Note2: Both MM-70DV01 and MM-RGB-E is installed at factory default.
