1.5 List of Tools Used
The tools used for installing projector are as follows:
Item Tool Quantity
Major Application
Phillips head screwdriver (No.2) 1 Covers Projector
(NC3200S/
Flat head screwdriver 1 Lens
NC3200S-A / Hexagonal wrench (Width across flats: 4 mm) 1 Lamp Bulb
NC3240S-A) Hexagonal wrench (Width across flats: 5 mm) 1 Lamp house
Spanner (Width across flats: 17 mm) 2 Power cable
Spanner (Width across flats: 19 mm) 1 Level adjuster
Box wrench (Width across flats: 17mm) 1 Lamp house
Phillips head screwdriver (No.2) 1 Covers Installation base
(NC-PD02)
Phillips head screwdriver (No.3) 1 Lamp power supply
Hexagonal wrench (Width across flats: 3mm) 1 Outer panel
Hexagonal wrench (Width across flats: 4mm) 1 Holder foot
Hexagonal wrench (Width across flats: 14mm) 1 Tilt metal
Spanner (Width across flats: 24mm) 1 Level adjuster
Phillips head screwdriver (No.2) 1 -
Hexagonal wrench (Width across flats: 5mm) 1 Front bracket, Lens
holder
Hexagonal wrench (Width across flats: 6mm) 1 Shaft L/R
Wide converter
lens turret
(NC-AT02)
Spanner (Width across flats: 10mm) 1 Adjust stopper bolt
Lens Hexagonal wrench (Width across flats: 2.5mm) 1 Lens adaptor
Option Board
(NC-80MB01/
NC-80LB01/
NC-80DS01)
Phillips head screwdriver (No.2) 1 -
