Projector Adjustment
and Connecting
3.1 Flow of Adjustment and Connecting
Adjustment and Connecting of the projector accord to the procedure below.
- Step1
Turning Your Projector On (See page 109)
- Step2
Setting The Date and Time in the Projector (See page 111)
- Step3
Setti
ng the Projector Projection Method (See page 112)
- Step4
A
djusting the Lamp Bulb Shaft (See page 113)
- Step5
A
djusting the Primary Lens (See page 115)
Di
splay the test pattern to adjust the screen size, screen ratio and focus.
- Step6
Adjusting the Wide Converter Lens (See page 118)
- Step7
Connecti
ng with the Image Input Port (See page 127)
- Step8
Co
nnecting the Various Control Terminal (See page 128)
Thi
s chapter explains the adjustment and connection of the projector with Steps 1 to 8.
Steps 1 to 8 complete the adjustment and connection of the projector. Next, carry out various
settings such as color adjustment using DCC for S2. Refer to the “Digital Cinema Communicator
for S2 Installation Manual” for the procedure.
To Next Page
