2. Setting Up Your Projector
90
2.6.4
Mounting of the Wide Converter Lens or Anamorphic Lens
This section describes the procedure for mounting the wide converter lens. If you are mounting
an anamorphic lens, please read wide converter lens as anamorphic lens.
[1] Loosen the two roll angle fixing knobs, then turn the lens holder
counterclockwise
and remove it from the slide unit.
Turn the lens holder’s knob hole to the position of the roll angle fixing knobs and pull the lens
holder towards you.
Caution
Pay attention not to have the finger caught when rotating the lens holder.
Lens Holder
Roll angle fixing knobs
To Next Page
