5. Steps to upgrade to 4K

164

[1] Remove the current CN6.

Remove the connector of the 4 places listed

below.

- Front upper FAN

- Turret for Wide converter lens

- Front underneath FAN

- Router power

[2] Connect the new CN6 to

PJDIV PWB.

Front underneath FAN

Front upper FAN

Turret for Wide converter lens

Router power
