2. Setting Up Your Projector
44
[7] Connect the dedicated interface
cable to the projector.
For connection procedure, refer to “2.3.5
Connecting the AC Power Supply Cable to the
Projec
tor” (Page 62).
Bund
le any excessive cables in connection of
dedicated interface cable at the back of the
pedestal.
Note
Mount the ferrite clamp core to dedicated interface cable of female connector side, when
using NC-32PS02 as lamp power supply. For procedure, refer to “2.3.5 Connecting the AC
Power Supply Cable to the Projector” (Page 62).
To Next Page
