2. Setting Up Your Projector

[3]

Nehmen Sie die Abdeckung der Lampen-Spannungsversorgung ab.

NC-32PS01: An zwei Stellen der Abdeckung sind Befestigungsschrauben angebracht.

NC-32PS02: An drei Stellen der Abdeckung sind Befestigungsschrauben angebracht.

NC-32PS01 (2 Stellen) NC-32PS02 (3 Stellen)
