Item No. Item Input Data Default Note
22 QSIG Operation Mode 0=Disable
1=Enable
0 (V1.5 Deleted)
24 Power feeding for S-point 0=Disable
1=Enable
0
For PRIU PKG Setup
ISDN Line Number 01 ~ 30
Item No. Item Input Data Default Note
01 ISDN Line Mode 0 = No setting
1 = T-Point
2 = S-Point
6 = S-Point (Leased Line)
1
02 Logical Port Number
The start port number
of a PRI line is
displayed.
[0:Nosetting]=0
[1:T-Point]=1~126
[2:S-Point]=1~128
[6 : S-Point (Leased Line)]=1~128
0
03 CRC Multi-frame (CRC4)
(Only for 2M = 30ch Mode)
0=off
1=on
1
04 Layer 3 Timer Type
Each timer value of
Layer 3 is set up for
each type in Program
81-06 (T-Bus)
1~5 1
05 CLIP Information
Based on this setting, the system
includes a Presentation Allowed
(1) or Presentation Restricted (0)
in the Setup message to allow or
deny the Calling Party Number.
Program 15-01-04 must also be
set to 1 if this option is enabled.
0=No
1=Yes
1
06 Length of Cable 0 = Level 1
1 = Level 2
2 = Level 3
3 = Level 4
4 = Level 5
2
07 S-point DDI digits 0-4 0
08 Dial Sending Mode
ISDN Protocol definition
0 = Enbloc Sending
1 = Overlap Sending
1
09 Dial Information Element
ISDN Protocol definition Only
when Dial Sending Mode (10-03-
08) is set for 1 (Overlap Send-
ing).
0 = Keypad Facility
1 = Called Party Number
1
10 Master/Slave System
If set to 0, system is synchro-
nized to network clock. If set to 1,
system is not synchronized to the
network clock.
0 = Slave System
1 = Master System
0 (V1.5 Deleted)
11 Networking System No. 0 ~ 50 0 (V1.5 Deleted)
ISSUE 1.1 SL1000
Program
10
Programming Manual 2-7
