Manage the Modem Router and Monitor the Traffic
162
N600 and AC750 WiFi DSL Modem Routers
3. Enter the user name and password for the modem router.
The user name is admin. The default password is password.
The user name and
password are case-sensitive.
4. Click the OK button.
The BASIC Home screen displays.
5. Select ADVANCED > ADV
ANCED Home.
The ADVANCED Home screen displays.
6. In the Internet Port pane, click the Show Statistics button.
The following table describes the fields and columns of the Show Statistics pop-up
screen.
Field or Column Description
System Up Time The time elapsed since the modem router was last restarted.
Port The statistics for the WAN (Internet link over Ethernet) port, LAN (Ethernet) ports,
and WLAN (WiFi) ports. For each port, the screen displays the information that is
described in this table.
Status The link status of the port.
TxPkts The number of packets transmitted on this port since reset or manual clear.
RxPkts The number of packets received on this port since reset or manual clear.
Collisions The number of signal collisions that occurred on the port. A collision occurs when
the port attempts to send data at the same time as the device that is connected to
the port.
Tx B/S The number of bytes transmitted per second on the port.
Rx B/S The number of bytes received per second on the port.
Up Time The time elapsed since this port acquired the link.
