Table 4. Router specifications (Continued)
DescriptionFeature
11.0 x 5.6 x 4.9 in. (282 x 142 x 124 mm)Dimensions
3.6 lb (1.635kg)Weight
0° to 40°C (32º to 104ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15, Subpart B, Class B
IECS-003: 2020 issue 7, Class B
EN 55032: 2015+A11:2020, Class B
EN 55035: 2017+A11:2020
EN 301 489-1 V2.2.3(2017-11)
EN 301 489-17 V3.2.4(2020-09)
AS/NZS CISPR 32: 2015+AMD1:2020, Class B
CISPR 32: 2015+AMD1:2019 ED2.0, Class B
CISPR 32: 2019 ED. 2.1, Class B
Electromagnetic emissions
One RJ-45 port compatible with 10GBASE-T, 1000BASE-TX, 100BASE-T, and
10BASE-T
WAN
Four RJ-45 ports compatible with 1000BASE-T, 100BASE-TX, and 10BASE-T
One RJ-45 port compatible with 10GBASE-T, 1000BASE-TX, 100BASE-T and
10BASE-T
LAN
Maximum WiFi signal rate complies with the IEEE 802.11 standard.
Note: Maximum wireless signal rate derived from IEEE 802.11 specifications.
Actual data throughput and wireless coverage will vary and may be lowered
by network and environmental conditions, including network traffic volume
and building construction. NETGEAR makes no representations or warranties
about this product’s compatibility with AX standards.
WiFi
2.4 GHz BE: 4x4 (Tx/Rx) 4096 QAM
40/20 MHz, up to 1.4 Gbps
5 GHz BE: 4x4 (Tx/Rx) 4096 QAM
20/40/80/160 MHz, up to 5.8 Gbps
6 GHz BE: 4x4 (Tx/Rx) 4096 QAM
20/40/80/160/320 MHz, up to 11.5 Gbps
Auto Rate SensingRadio data rates
2.4 GHz radio: Supports IEEE 802.11 b/g/n/ac/ax/be with 4096-QAM, 20/40
MHz channel width
5 GHz radio: Support IEEE 802.11 b/g/n/ac/ax/be with 4096-QAM,
20/40/80/160 MHz channel width
6 GHz radio: Supports IEEE 802.11 ax/be with 4096-QAM, 20/40/80/160/320
MHz channel width,
Data encoding standards
200Maximum number of
connected devices
User Manual217Supplemental Information
Nighthawk WiFi 7 Tri-Band Router Model RS700
