Neural QUAD CORTEX - Page 99

99Hardware specications
USB AUDIO
GENERAL
ENVIRONMENTAL INFORMATION
• FORMAT: USB Audio Class 2.0 Compliant
• CHANNELS: 16 (8IN/8OUT)
• AUDIO CLOCK: 48kHz (FIXED)
• FINISH: Anodized aluminum unibody
• CONTROLS:
• 11 Stainless Steel Stomp + Rotary Footswitches
• 1 Master Volume Knob
• 1 Power Switch
• DISPLAY: 7” High-Brightness
• DIMENSIONS: 29 x 19.5 x 6.9CM / 11.4” x 7.7”
• WEIGHT: 1.95KG / 4.2LBS
• INPUT VOLTAGE: 12VDC 3A (Center Negative)
• TYPICAL POWER CONSUMPTION: 18W
• OPERATING TEMP: 32 to 122 °F (0 to 50 °C)
• STORAGE TEMP: 14 to 158 °F (-10 to 70 °C)
• HUMIDITY: Maximum Non-Condensing
EXPRESSION INPUTS 1/2
MIDI PORTS
• CONNECTORS: (2) ¼” TRS-F
• INPUT CONNECTOR: 5-pin DIN
• OUTPUT CONNECTOR: 5-pin DIN
