Neural QUAD CORTEX - Hardware Specifications

98Hardware specications
Hardware specications
13
COMBO INPUTS 1/2
SEND OUTPUTS 1/2
RETURN INPUTS 1/2
XLR OUTPUTS 1/2
TRS OUTPUTS 3/4
• CONNECTORS: (2) XLR-F + ¼” TS-F (GROUND LIFT)
• TS IMPEDANCE: 10KΩ - 10MΩ
• XLR IMPEDANCE: 9.4K Ω
• MAX INPUT GAIN: +60dB
• CONNECTORS: (2) ¼” TRS-F (GROUND LIFT)
• IMPEDANCE: 1MΩ
• MAX INPUT GAIN: +60dB
• CONNECTORS: (2) XLR-M (GROUND LIFT)
• IMPEDANCE: 560Ω
• MAX INPUT GAIN: +9.5dBu
• CONNECTORS: (2) ¼” TRS-F
• IMPEDANCE: 560Ω
• MAX OUTPUT LEVEL: +15.5dBu balanced, +9.5dBu unbalanced
• CONNECTORS: (2) ¼” TRS-F (GROUND-CANCELLING)
• IMPEDANCE: 560Ω
• MAX OUTPUT LEVEL: +9.5dBu
HEADPHONES OUTPUT
• CONNECTOR: ¼” TRS-F
• MAX OUTPUT POWER: 300mW
