Scrub System, REV 103Service Manual – SC500
Specications
Description / Model
Advance
SC500 20 RB
Cleaning width 20 in (530 mm)
Brush/pad diameter 20 in (530/508 mm)
Brush pressure with extra-pressure function turned off
49 lb (22 kg)
Brush pressure with extra-pressure function turned on
66 lb (30 kg)
Brush deck right/left offset 100 / 25 mm (3.9 / 1 in)
Brush distance from the oor (when lifted) 1.9 in (48 mm)
REV motor power 0.9 HP (670 W)
Rotation speed 2200 RPM
Insulation class H
Actuator technical data
Strength
300 N
Maximum load
600 N
Regulated travel
2.5 in (63 mm)
Total travel
3.8 in (98 mm)
Voltage
24V
Protection class
IP 44
Insulation class
B
No-load current draw
0.5A
Full-load current draw
3A
