Chassis System 18Service Manual – SC500
Chassis System
Chassis (main parts)
The chassis function is primarily performed by the solution tank, the support housings for the wheels and working
mechanisms are integrated in the gear motor unit and the rear frame.
Reference to Figure 1
• Deck raising levers (see also Brush System, Disc and Brush System, REV)
• Frame integrated in the drive motor (see also Wheels System, Drive)
• Rear pivoting wheels support frame with squeegee raising/lowering system (see also Squeegee System)
Brush deck raising levers
Drive gear motor with
integrated frame
Figure 1
Rear pivoting wheels support frame with squeegee
raising/lowering system
