Electrical System 58Service Manual – SC500
Maintenance and Adjustments
Setting the Installed Battery Type
Set the machine and the on-board battery charger (where tted) on the basis of the type of battery to be in-
stalled by modifying the BAT parameter as indicated.
1. Insert the Super User (yellow) key in place of the operator (grey) key to access the main screen (Figure
4) of the multifunction display.
2. Press the One-Touch button to continue to the machine settings screen (Figure 5).
Figure 4
Figure 5
3. Press the One-Touch button until you reach the BAT parameter.
MODIFIABLE PARAMETERS
Code Description Min. Value Factory Setting Max. Value
BAT Installed battery type 0 1 5
4. Press the “hare” or “tortoise” button to modify the value of the BAT parameter as per the
following table:
Code BAT
Value Installed battery type
0 WET Wet cell batteries
1 GEL / AGM Generic GEL or AGM batteries
2 GEL EXIDE EXIDE
®
/SONNENSHINE brand GEL batteries
3 GEL OPTIMA OPTIMA brand GEL batteries
4 GEL DISCOVER DISCOVER
®
brand GEL batteries
5 GEL FULLRIVER FULLRIVER
®
brand GEL batteries
5. Press the brush release button to conrm the chosen parameter and return to the main screen
(Figure 4).
