Solution System 105Service Manual – SC500
Component Locations
• Solution tank
• Detergent solution tank side ller cap
• Detergent solution tank front ller
• Water removable ller hose
• Solution drain and level check hose
• Solution tap
• Solution lter
• Solenoid valve (EV1)
• Battery compartment liquid drain hole
Detergent solution tank
front ller
Detergent solution tank
side ller cap
Water removable ller
hose
Solution tank
Figure 2
Solution drain and level
check hose
Figure 3
