Squeegee System 118Service Manual – SC500

Component Locations

• Upper squeegee support

• Impact deection wheel

• Squeegee blades

• Gas spring

• Squeegee lifting/lowering pedal

• Squeegee adjusting knob

• Lower squeegee support

• Mounting handwheels

• Squeegee blades

Squeegee adjusting knob

Lower squeegee

support

Mounting handwheels

Impact deection

wheel

Upper squeegee

support

Squeegee lifting/

lowering pedal

Gas spring

Squeegee blades

Figure 1
