Recovery System 68Service Manual – SC500
Component Locations
• Recovery tank
• Recovery tank cover
• Cover gasket
• Vacuum motor lter
• Recovery water drain hose
• Squeegee vacuum hose
• Vacuum motor (M2)
• Container with debris collection grid
• Vacuum grid with automatic shut-off oat
Cover gasket
Container with debris
collection grid
Recovery tank
Recovery tank cover
Figure 2
Vacuum grid with
automatic shut-off oat
Vacuum motor (M2)
Squeegee
vacuum hose
Recovery water drain
hose
Figure 3
Motor protection case
