Nilfisk-Advance SC500 Service Manual

Solution System 115Service Manual – SC500
Water Level Sensor Disassembly/Assembly
1. Drive the machine on a level oor.
2. Switch off the machine and disconnect the battery connector.
3. Lift the recovery tank.
4. Unscrew the two screws (A) (Figure 13) and remove the cover (B).
5. Unscrew the two screws (C) and lift the tank (D).
6. Disconnect the connector (E).
7. Disassemble and remove the water level sensor (F).
Assembly
8. Assemble the components in the reverse order of disassembly.
Figure 13
B
A
C
D
F
D
E
A
