Electrical System 58Service Manual – SC500
Battery Charging (Continues)
Warning! When using lead (WET) batteries, battery charging produces highly explosive
hydrogen gas. Charge the batteries in well-ventilated areas and away from naked
ames. Do not smoke while charging the batteries. Keep the recovery tank raised
until the battery charging cycle is over.
Warning! Pay close attention when charging WET CELL batteries, as there may be battery uid
leakages. The battery uid is corrosive. If it comes in contact with skin or eyes, rinse
thoroughly with water and consult a physician.
1. (For WET CELL batteries only) Check the level
of electrolyte inside the batteries. If necessary,
unscrew the caps and top up.
2. When the correct level is restored, close the caps
and clean the tops of the batteries.
Charging the Batteries with an External Battery
Charger
3. Check that the external battery charger is
suitable by referring to the relevant Manual.
The battery charger voltage rating must be 24V.
4. Disconnect the red battery connector and
connect it to the external battery charger.
5. Connect the battery charger to the electrical
mains.
6. After charging, disconnect the battery charger
from the electrical mains and from the battery
red connector.
7. Connect the battery connector to the machine.
8. Carefully lower the recovery tank.
Battery charging with battery charger installed on
the machine
9. Plug the battery charger into the mains
electricity supply (the mains voltage and
frequency must be compatible with the battery
charger values shown on the machine serial
number plate).
Note: When the battery charger is
connected to the electrical
mains, all machine functions
are automatically cut off.
10. When the rst or second segment from the left in
the battery symbol is ashing, this means that
the battery charger is charging the batteries.
11. When the third segment from the left in the
battery symbol is ashing, this means that the
battery charger is nishing the battery charging
cycle.
12. When all segments of the battery symbol
are steadily lit, the battery charging cycle is
complete.
13. Disconnect the battery charger plug from the
mains and place it in its holder.
14. Carefully lower the recovery tank.
Note: For further information about
the operation of the battery
charger, see the relevant
Manual.
