Nordson Encore Series User Manual

Parts
7-3
Part 1612500−02
E 2018 Nordson Corporation
See Figure 7-18 and the list below.
Item Part Description Quantity Note
− 1601416 SPRAY GUN, manual, Encore PE 1
1 1601811
S RETAINER, deflector, 38 mm, Encore PE
1
2 245523
S DEFLECTOR, 38 mm diameter, ceramic
1
3 945016
SS O-RING, silicone, 0.251 x 0.40 x 0.074 in.
1
4 246578
S INSERT, Pyrex
1
5 940331
S O-RING, silicone, 2.00 x 2.175 x 0.063 in.
1
6 942240
S O-RING, hot paint, 1.75 x 2.00 x 0.125 in.
1
7 982455
S SCREW, SET, M6 x 1.0 x 8, nylon, black
1
8 1601433
S SLEEVE, pattern adjuster, Encore PE
1
9 1602039
S O-RING, Buna-N, 46 x 3, 70 duro
1
10 1601430
S NOZZLE, conical, Encore PE
1
11 1601431
S NUT, nozzle, Encore PE
1
12 1601422
S RING, retaining, nozzle, Encore PE
1
13 1601814
S HOLDER, electrode, conical, Encore PE
1
14 1602041
S ELECTRODE, spring contact, Encore PE
1
15 1612354
S SUPPORT assembly, electrode, Encore PE, XD
1 A, B
16 1612461
SS O-RING, Buna N, 24.0 mm x 1.00 mm
1
17 1088506
S KIT, body assembly, spray gun, Encore PE
1
18 1088558
SS FILTER assembly, spray gun
1
19 1084821
S POWER SUPPLY, 100 kv, Encore, packaged
1
20 1601437
S ELBOW, assembly, spray gun, Encore PE
1
21 940163
SS O-RING, silicone, 0.625 x 0.75 x 0.063 in.
1
22 1088502
S GASKET, multiplier cover, spray gun, Encore PE
1
23 1106872
S BULKHEAD, multiplier, spray gun, Encore PE
1
24 1087559
S COVER, spray gun display housing, Encore
1
25 1087558
S HOUSING, spray gun display, Encore
1
26 1087760
S HOOK, spray gun, Encore
1
27 1078075
S SCREW, Phillips head, M3 x 30 zinc plate
1
28 1601754
S LABEL, spray gun, Encore
1
29 760580
S SCREW, Phillips head, M3 x 20 zinc plate
3
30 1106871
S HANDLE, ground pad, spray gun Encore LT/XT
1
31 1081777
S RETAINING RING, external, 10 mm E−Ring
1
32 1106756
S CABLE ASSEMBLY, spray gun, Encore LT/XT, 6 m
1
33 1604500
S CLAMP, cable, 0.25 ID x 0.05 thick, white
1
34 1108095
S KIT, trigger switch, Encore
1
35 1601439
S INLET assembly, powder, Encore PE
1
36 1084773
SS O−RING, silicone, 18 mm ID x 2 mm W, 70 duro
2
37 1601756
S ADAPTER assembly, hose, spray gun, M,
Encore PE
1
38 940157
SS O-RING, Viton, black, 0.563 x 0.688 x 10415
2
39 1081617
S CHECK VALVE, male, M5 x 6 mm tube
1
40 1081616
S FITTING, bulkhead, barbed, dual, 10−32 x 4 mm
tubing
1
41 1087762
S BASE, handle, spray gun, Encore
1
42 1106870
S HANDLE, spray gun, Encore LT/PE
1
Continued...

Nordson Encore Series Specifications

General

Maximum Output Voltage	100 kV
Power Source	Electric
Maximum Powder Output	20 lbs/hr (9.07 kg/hr)
Air Consumption	10-15 CFH (4.7-7.1 L/min)
Application	Powder coating
Technology	Electrostatic
Maximum Flow Rate	20 lbs/hr (9.07 kg/hr)
Weight	1.5 lbs (0.68 kg)
