Nordson Encore Series User Manual

Parts
7-4
Part 1612500−02
E 2018 Nordson Corporation
NoteQuantityDescriptionPartItem
43 1606999
S KIT, trigger w/ axle, Encore
1
44 1106892
SS ACTUATOR, switch, trigger, Encore XT/LT
1
45 −−−−−−−
SS AXLE, trigger, solid, spray gun, Encore
1
46 1081540
S INLET, assembly, powder, Encore PE
1
47 1088601
S SCREW, flat head, recessed, M5 x 10 nylon
1
48 982427
S MACHINE SCREW, pan head, M3 x 6 zinc
1
49 983520
S WASHER, lock, internal, M3, steel, zinc
1
50 940129
S O−RING, silicone, conductive, 0.375 x 0.50 in.
1
NS 900617
S TUBE, polyurethane, 4 mm OD, clear
AR C
NS 900741
S TUBING, polyurethane, 6/4 mm, black
AR C
NS 900620
S TUBING, poly, spiral cut ⅜ in. ID
AR C
NOTE A: Refer to Figure 7-19 and parts list for repair parts for the XD Electrode Support Assembly kit.
B: Refer to Figure 7-20 and parts list for repair parts for the optional SD Electrode Support Assembly kit.
C: Refer to Powder Hose and Air Tubing on page 7−11 for minimum order quantities.

Nordson Encore Series Specifications

General

Maximum Output Voltage	100 kV
Power Source	Electric
Maximum Powder Output	20 lbs/hr (9.07 kg/hr)
Air Consumption	10-15 CFH (4.7-7.1 L/min)
Application	Powder coating
Technology	Electrostatic
Maximum Flow Rate	20 lbs/hr (9.07 kg/hr)
Weight	1.5 lbs (0.68 kg)
