NORMALAB NDI 450 - Page 33

NORMALAB France
2012
N O R M A L A B F r a n c e
33/118
Position of the pump
Remove the 2 fixing screws
Or remove the 4 nuts and lift the assembly and
rotate it
And remove the 2 fixing screws of the pump
Remove insulation fitting and disconnect them
Remove the frame fixations
1
2
