Type Codes for Input Devices Appendix F: Type Codes
NFS-640 Programming Manual P/N 51333:B 10/03/2003 105
Type Codes for Monitor Modules
A list of monitor module Type Codes, which you can use to change the function of a monitor module
point.
Table 33 Type Codes for Monitor Modules
Type Code
Point Characteristics
Device Function
Point
Type
Latching
(Y/N)
Point Function
MONITOR fire alarm Y Lights fire alarm LED and activates CBE Alarm-monitoring device
PULL STATION fire alarm Y Lights fire alarm LED and activates CBE Manual fire-alarm-activating device, such as a pull station
RF MON MODUL fire alarm Y Lights fire alarm LED and activates CBE Wireless alarm-monitoring device
RF PULL STA fire alarm Y Lights fire alarm LED and activates CBE Wireless manual fire-alarm-activating device, such as a pull station
SMOKE CONVEN fire alarm Y Lights fire alarm LED and activates CBE Indicates activation of a conventional smoke detector
attached to an FZM-1
SMOKE DETECT fire alarm Y Lights fire alarm LED and activates CBE Indicates activation of a conventional smoke detector
attached to an FZM-1
WATERFLOW fire alarm Y Lights fire alarm LED and activates CBE Monitor for waterflow alarm switch
WATERFLOW S supervisory Y Lights supervisory LED and activates
CBE
Indicates supervisory condition for activated waterflow switch
ACCESS MONTR non-alarm N Activates CBE Used for monitoring building access
AREA MONITOR security Y Lights security LED and activates CBE Monitors building access
AUDIO SYSTEM trouble N Activates CBE and lights trouble LED Used for monitoring audio equipment
EQUIP MONITR trouble N Activates CBE and lights trouble LED Used for recording access to monitored equipment
RF SUPERVSRY supervisory N Lights Supervisory LED Monitors a radio frequency device
SECURITY security Y Lights security LED Indicates activation of security alarm
LATCH SUPERV supervisory Y Lights supervisory LED Indicates latching supervisory condition
TRACK SUPERV supervisory N Lights supervisory LED Monitors for waterflow tamper switches for alarm points
SPRINKLR SYS supervisory Y Lights supervisory LED Monitors a waterflow device
SYS MONITOR security Y Lights security LED and activates CBE Monitors equipment security
TAMPER supervisory Y Lights supervisory LED, activates CBE Indicates activation of tamper switch
ACK SWITCH non-alarm N Emulates panel Acknowledge switch, no
CBE
Silences panel sounder, gives an Acknowledge message
on the panel LCD
ALLCALL PAGE non-alarm N Activates all speaker circuits, no CBE Emulates AMG-1 All-call switch
DRILL SWITCH non-alarm N Emulates panel Drill switch Activates silenceable outputs
EVACUATE SWITCH non-alarm N Emulates keypad Drill Switch Activates all silenceable outputs
FIRE CONTROL non-alarm Y Activates CBE Used for non-fire activation of outputs
NON FIRE non-alarm N Activates CBE Used for building energy management
PAS INHIBIT non-alarm N Inhibits Positive Alarm Sequence Inhibits Positive Alarm Sequence
POWER MONITR trouble N Indicates trouble, activates CBE Monitors auxiliary power supplies
RESET SWITCH non-alarm N Emulates keypad Reset switch Resets control panel
SIL SWITCH non alarm N Emulates keypad Signal Silence switch Turns off all activated silenceable outputs
TELE PAGE non-alarm N Emulates Page Button on FFT-7 Allows remote paging to a fire area
TROUBLE MON trouble N Indicates Trouble and activates CBE Monitors trouble inputs
ABORT SWITCH non alarm N Indicates Active at the panel Aborts activation of a releasing zone
MAN RELEASE fire alarm Y Lights Fire Alarm LED and activates
CBE
Indicates activation of a monitor module programmed to
releasing zone to perform a releasing function
MANREL DELAY fire alarm Y Lights Fire Alarm LED and activates
CBE
Indicates activation of a monitor module programmed for
a release output
SECOND SHOT fire alarm Y Indicates Active at the panel and activates
CBE
Provides second activation of releasing zone after soak
timer has expired.
Blank fire alarm Y Lights fire alarm LED and activates CBE Monitors for a device with no description
HEAT DETECT fire alarm Y Lights fire alarm LED and activates CBE Monitors for conventional heat detector
