Notifier NFS-640 Programming Manual

CBE Example Appendix D: CBE (Control-By-Event)
NFS-640 Programming Manual P/N 51333:B 10/03/2003 99
CBE Example
An example of CBE, where monitor module 1M101 lists zone Z04 and Z05, and control module 1M108
lists zone Z05 and zone Z07:
Figure 32 CBE Example
When monitor module 1M101 activates, the following CBE takes place:
1. Software Zones Z04 and Z05 activate.
2. Since control module 1M108 has Z05 in its CBE list, all of its outputs would activate. All output
devices with Z04 or Z05 would activate.
Both devices contain zone Z05 in its CBE list
Software
Zone Z05
Monitor
Module
1M101
Control
Module
1M108
CBE=Z04 Z05
CBE=Z05 Z07
PROGRAM MONITOR MODULE ADDR 1M101
04 05 __ __ __ 1M101
PROGRAM CONTROL MODULE ADDR 1M108
05 07 __ __ __ 1M108
