MS51

Nov. 28, 2019 Page 16 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

3.3 MS51 Series Selection Code

Core

Line

Package

Flash

SRAM

Reserve

Temperature

1T 8051

Industry

51: Base

B: MSOP10 (3x3 mm)

D: TSSOP14 (4.4x5.0 mm)

E: TSSOP28 (4.4x9.7 mm)

F: TSSOP20 (4.4x6.5 mm)

I: SOP8 (4x5 mm)

O: SOP20 (300 mil)

P: LQFP32 (7x7 mm)

T: QFN33 (4x4 mm)

U: SOP28 (300 mil)

X: QFN20 (3x3mm)

A: 8 KB

B: 16 KB

C: 32 KB

0: 2 KB

1: 4 KB

2: 8/12 KB

3: 16 KB

6: 32 KB

8: 64 KB

9: 1 KB

A: 96 KB

E:-40 ~ 105°C
