MS51

Nov. 28, 2019 Page 27 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

CONFIG1

LDSIZE[2:0]

R/W

Factory default value: 1111 1111b

Bit

Name

Description

2:0

LDSIZE[2:0]

LDROM size select

This field selects the size of LDROM.

111 = No LDROM. APROM is 32 Kbytes.

110 = LDROM is 1 Kbytes. APROM is 31 Kbytes.

101 = LDROM is 2 Kbytes. APROM is 30 Kbytes.

100 = LDROM is 3 Kbytes. APROM is 29 Kbytes.

0xx = LDROM is 4 Kbytes. APROM is 28 Kbytes.

[1] The logic boundary addresses of APROM and LDROM are defined by CONFIG1[2:0].

LDROM

0000H

CHPCON[1] BS = 1

0000H

CHPCON[1] BS = 0

APROM

32K bytes

SPROM

FFFFH

FF80H

SPROM

0FFFH

[1]

0BFFH

[1]

07FFH

[1]

03FFH

[1]

7FFFH

7C00H

[1]

7800H

[1]

7400H

[1]

7000H

[1]

CONFIG

0000H

Figure 6.1-1 MS51 Program Memory Map
