Instruction
OPCODE
Bytes
Clock
Cycles
MS51 V.S. Tradition
80C51 Speed Ratio
ORL C, bit
72
2
3
8
ORL C, /bit
A0
2
3
8
MOV C, bit
A2
2
3
4
MOV bit, C
92
2
4
6
ACALL addr11
11, 31, 51, 71, 91, B1, D1, F1
[2]
2
4
6
LCALL addr16
12
3
4
6
RET
22
1
5
4.8
RETI
32
1
5
4.8
AJMP addr11
01, 21, 41, 61, 81, A1, C1, E1
[3]
2
3
8
LJMP addr16
02
3
4
6
SJMP rel
80
2
3
8
JMP @A+DPTR
73
1
3
8
JZ rel
60
2
3
8
JNZ rel
70
2
3
8
JC rel
40
2
3
8
JNC rel
50
2
3
8
JB bit, rel
20
3
5
4.8
JNB bit, rel
30
3
5
4.8
JBC bit, rel
10
3
5
4.8
CJNE A, direct, rel
B5
3
5
4.8
CJNE A, #data, rel
B4
3
4
6
CJNE Rn, #data, rel
B8~BF
3
4
6
CJNE @Ri, #data, rel
B6, B7
3
6
4
DJNZ Rn, rel
D8~DF
2
4
6
DJNZ direct, rel
D5
3
5
4.8
Note：
[1] The MS51 does not have external memory bus. MOVX instructions are used to access internal XRAM.
[2] The most three significant bits in the 11-bit address [A10:A8] decide the ACALL hex code. The code will be
[A10,A9,A8,1,0,0,0,1].
[3] The most three significant bits in the 11-bit address [A10:A8] decide the AJMP hex code. The code will be
[A10,A9,A8,0,0,0,0,1].
