Nuvoton NuMicro MS51PC0AE - Table 6.10-1 Smart Card or UART Pin Define and Enable Control Register

MS51
Nov. 28, 2019 Page 388 of 491 Rev 1.00
MS51 32K SERIES TECHNICAL REFERENCE MANUAL
URAT Pin
SC Pin
Pin Name
SFR Define
SFR Byte Name
SFR Bit Name
Value
P1.7
10
UART3_TXD
SC1_CLK
P1.2
AUXR3[3:2]
UART3TXP
01
P1.5
10
P0.5
11
UART3_RXD
SC1_DAT
P1.1
AUXR3[1:0]
UART3RXP
01
P2.5
10
P3.4
11
UART4_TXD
SC2_CLK
P2.3
AUXR3[7:6]
UART4TXP
01
UART4_RXD
SC2_DAT
P2.2
AUXR3[5:4]
UART4RXP
01
Table 6.10-1 Smart Card or UART Pin Define And Enable Control Register
6.10.2 Operating Modes
ISO 7816-3 Mode 6.10.2.1
The ISO 7816-3 Interface controller supports activation, cold reset, warm reset and deactivation
sequence by software control. The activation, cold reset, warm reset and deactivation and sequence
are shown as follows.
SC Interface Connection
The SC interface connection is shown in Figure 15.3-1
1. SCn_CLK / UARTn_TXD : SC clock pin (output from MCU)
2. SCn_DAT / UARTn_RXD : SC data pin (bi-directional)
3. SCn_RST: SC reset pin (output from MCU, firmware assigned GPIO)
4. SCn_PWR: SC power pin (output from MCU, firmware assigned GPIO)
5. *: SCn_PWR is used for power control function to turn ON/OFF the power for ISO 7816-3. Do not
use SCn_PWR as the direct power supply for ISO 7816-3.
6. SCn_CD: SC card detect pin (input to MCU, detect card by a card insert mechanism)
