Nov. 28, 2019 Page 223 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

CHPCON – Chip Control

SFR Address

Reset Value

CHPCON

9FH, All page, TA protected

Software 0000_00U0 b

Others 0000_00C0 b

SWRST

IAPFF

IAPEN

R/W

Bit

Name

Description

SWRST

Software reset

To set this bit as logic 1 will cause a software reset. It will automatically be cleared via hardware

after reset is finished.
