MS51

Nov. 28, 2019 Page 280 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PnSR –Port n Slew Rate Control

SFR Address

Reset Value

P0SR

B2H, Page 1

0000_0000 b

P1SR

B4H, Page 1

0000_0000 b

P2SR

8BH, Page 2

0000_0000 b

P3SR

ADH, Page 1

0000_0000 b

PnSR.7

PnSR.6

PnSR.5

PnSR.4

PnSR.3

PnSR.2

PnSR.1

PnSR.0

R/W

Bit

Name

Description

7:0

PnSR[7:0]

Pn slew rate

0 = Pn.x normal output slew rate.

1 = Pn.x high-speed output slew rate.
