MS51

Nov. 28, 2019 Page 283 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PINEN – Pin Interrupt Negative Polarity Enable.

SFR Address

Reset Value

PINEN

EAH, Page 0

0000_0000 b

PINEN7

PINEN6

PINEN5

PINEN4

PINEN3

PINEN2

PINEN1

PINEN0

R/W

Bit

Name

Description

PINENn

Pin interrupt channel n negative polarity enable

This bit enables low-level/falling edge triggering pin interrupt channel n. The level or edge triggered

selection depends on each control bit PITn in PICON.

0 = Low-level/falling edge detect Disabled.

1 = Low-level/falling edge detect Enabled.
