MS51

Nov. 28, 2019 Page 285 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PIF – Pin Interrupt Flags

SFR Address

Reset Value

PIF

ECH, Page 0

0000_0000 b

PIF7

PIF6

PIF5

PIF4

PIF3

PIF2

PIF1

PIF0

R (level)

R/W (edge)

R (level)

R/W (edge)

R (level)

R/W (edge)

R (level)

R/W (edge)

R (level)

R/W (edge)

R (level)

R/W (edge)

R (level)

R/W (edge)

R (level)

R/W (edge)

Bit

Name

Description

PIFn

Pin interrupt channel n flag

If the edge trigger is selected, this flag will be set by hardware if the channel n of pin interrupt

detects an enabled edge trigger. This flag should be cleared by software.

If the level trigger is selected, this flag follows the inverse of the input signal’s logic level on the

channel n of pin interrupt. Software cannot control it.
