Nov. 28, 2019 Page 30 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

CONFIG1

LDSIZE[2:0]

R/W

Factory default value: 1111 1111b

Bit

Name

Description

2:0

LDSIZE[2:0]

LDROM size select

Part number is MS51:

111 = No LDROM. APROM is 32 Kbytes.

110 = LDROM is 1 Kbytes. APROM is 31 Kbytes.

101 = LDROM is 2 Kbytes. APROM is 30 Kbytes.

100 = LDROM is 3 Kbytes. APROM is 29 Kbytes.

0xx = LDROM is 4 Kbytes. APROM is 28 Kbytes.
