Nov. 28, 2019 Page 304 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

RCMP2H – Timer 2 Reload/Compare High Byte

SFR Address

Reset Value

RCMP2H

CBH, Page 0

0000_0000 b

RCMP2H[7:0]

R/W

Bit

Name

Description

7:0

RCMP2H[7:0]

Timer 2 reload/compare high byte

This register stores the high byte of compare value when Timer 2 is configured in compare

mode. Also it holds the high byte of the reload value in auto-reload mode.
