MS51 32K SERIES TECHNICAL REFERENCE MANUAL

TH2 – Timer 2 High Byte

SFR Address

Reset Value

TH2

CDH, Page 0

0000_0000 b

TH2[7:0]

R/W

Bit

Name

Description

7:0

TH2[7:0]

Timer 2 high byte

The TH2 register is the high byte of the 16-bit counting register of Timer 2.

Note that the TH2 and TL2 are accessed separately. It is strongly recommended that user stops Timer

2 temporally by clearing TR2 bit before reading from or writing to TH2 and TL2. The free-running

reading or writing may cause unpredictable result.
