MS51

Nov. 28, 2019 Page 313 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

CAPCON4 – Input Capture Control 4

SFR Address

Reset Value

CAPCON4

F2H, Page 0

0000_0000 b

CAP23

CAP22

CAP21

CAP20

R/W

Bit

Name

Description

[3:0]

CAP2[3:0]

Input capture channel 2 input pin select

0000 = P1.2/IC0

0001 = P1.1/IC1

0010 = P1.0/IC2

0011 = P0.0/IC3

0100 = P0.4/IC3

0101 = P0.1/IC4

0110 = P0.3/IC5

0111 = P0.5/IC6

1000 = P1.5/IC7

others = P1.2/IC0
