MS51

Nov. 28, 2019 Page 33 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

CONFIG4

WDTEN[3:0]

R/W

Factory default value: 1111 1111b

Bit

Name

Description

7:4

WDTEN[3:0]

WDT enable

This field configures the WDT behavior after MCU execution.

1111 = WDT is Disabled. WDT can be used as a general purpose timer via software control.

0101 = WDT is Enabled as a time-out reset timer and it stops running during Idle or Power-down

mode.

Others = WDT is Enabled as a time-out reset timer and it keeps running during Idle or Power-

down mode.

3:0

Reserved
