MS51 32K SERIES TECHNICAL REFERENCE MANUAL

CKCON – Clock Control

SFR Address

Reset Value

CKCON

8EH, Page0

0000_0000b

PWMCKS

T1M

T0M

T0OE

CLOEN

R/W

Bit

Name

Description

PWMCKS

PWM clock source select

0 = The clock source of PWM is the system clock FSYS.

1 = The clock source of PWM is the overflow of Timer 1.
