MS51
Nov. 28, 2019 Page 347 of 491 Rev 1.00
MS51 32K SERIES TECHNICAL REFERENCE MANUAL
PIOCON0 – PWM or I/O Select
Register
SFR Address
Reset Value
PIOCON0
DEH, Page 0
0000_0000 b
7
6
5
4
3
2
1
0
-
-
PIO05
PIO04
PIO03
PIO02
PIO01
PIO00
-
-
R/W
R/W
R/W
R/W
R/W
R/W
Bit
Name
Description
5
PIO05
P0.3/PWM pin function select
0 = P0.3/PWM pin functions as P0.3.
1 = P0.3/PWM pin functions as PWM0C5/PWM3_CH1 output.
(PWM3_CH1P=11, select PWM3_CH1; others select PWM0C5)
4
PIO04
P0.1/PWM pin function select
0 = P0.1/PWM pin functions as P0.1.
1 = P0.1/PWM pin functions as PWM0C4/PWM3_CH0 output.
(PWM3_CH0P=10, select PWM3_CH0; others select PWM0C4)
3
PIO03
P0.0/PWM pin function select
0 = P0.0/PWM pin functions as P0.0.
1 = P0.0/PWM pin functions as PWM0_CH3/PWM2_CH1 output.
(PWM2_CH1P=10, select PWM2_CH1; others select PWM0_CH3)
2
PIO02
P1.0/PWM pin function select
0 = P1.0/PWM pin functions as P1.0.
1 = P1.0/PWM pin functions as PWM0_CH2/PWM2_CH0 output.
(PWM2_CH0P=10, select PWM2_CH0; others select PWM0_CH2)
1
PIO01
P1.1/PWM pin function select
0 = P1.1/PWM pin functions as P1.1.
1 = P1.1/PWM pin functions as PWM0_CH1/PWM1_CH1 output.
(PWM1_CH1P=11, select PWM1_CH1; others select PWM0_CH1)
0
PIO00
P1.2/PWM pin function select
0 = P1.2/PWM pin functions as P1.2.
1 = P1.2/PWM pin functions as PWM0C0/PWM1_CH0 output.
(PWM1_CH0P=11, select PWM1_CH0; others select PWM0_CH1)
