MS51

Nov. 28, 2019 Page 351 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

AUXR5 – Auxiliary Register 5

SFR Address

Reset Value

AUXR5

A4H, Page 2

0000_0000 b

CLOP

T0P

PWM3_CH1P

PWM3_CH0P

R/W

Bit

Name

Description

3:2

PWM3_CH1P

PWM3 channel 1 pin select

00 = Reserved by default

01 = Assign PWM3_CH1 to P3.4

10 = Assign PWM3_CH1 to P1.5

11 = Assign PWM3_CH1 to P0.3

1:0

PWM3_CH0P

PWM3 channel 0 pin select

00 = Reserved by default

01 = Assign PWM3_CH0 to P3.2

10 = Assign PWM3_CH0 to P0.1

11 = Reserved
