Nov. 28, 2019 Page 38 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

SFRS – SFR Page Selection

SFR Address

Reset Value

SFRS

91H, All page

0000_0000 b

SFRPAGE1

SFRPAGE0

R/W

Bit

Name

Description

1:0

SFRPAGE[1:0]

SFR page select

0 = Instructions access SFR page 0.

1 = Instructions access SFR page 1.

2 = Instructions access SFR page 2.

Switch SFR page demo code:

MOV SFRS,#01H

MOV SFRS,#00H
