NV5128 Multi-Format Router • User’s Guide 93
A. Part Numbers
Appendix A provides part numbers for cards, card sets and backplanes used for the NV5128. It dis-
cusses the following topics:
• Cards, Card Sets, and Backplanes
• Power Supplies
Cards, Card Sets, and Backplanes
Analog and Digital Audio
This table lists all the audio I/O cards and associated backplanes:
Part Name or Function Backplane(s) Slots Compatible with...
EM0389 AES synchronous input module EM0393 (BNC)
EM0391 (TP)
1 EM0586 (analog audio out)
EM0390 (sync AES out)
EM0390 AES synchronous output
module
EM0394 (BNC)
EM0392 (TP)
1 EM0585 (analog audio in)
EM0389 (sync AES in)
EM0387 AES asynchronous input
module
EM0393 (BNC)
EM0391 (TP)
1 EM0388 (async AES out)
EM0388 AES asynchronous output
module
EM0394 (BNC)
EM0392 (TP)
1 EM0387 (async AES in)
EM0500 AES sample rate converter
(SRC) input module
EM0393 (BNC)
EM0391 (TP)
1 EM0586 (analog audio out)
EM0390 (sync AES out)
EM0585 Analog Audio input module EM0381 (DB25) 1 EM0586 (analog out)
EM0388 (sync AES out)
EM0586 Analog Audio output module EM0382 (DB25) 1 EM0585 (analog in)
EM0389 (sync AES in)
Note The abbreviation “TP” in the above table denotes Phoenix-type connectors used for
shielded twisted-pair cables.
