88 Rev 2.3 • 14 Oct 08
7. Technical Details
Time Code Specifications
Time Code Specifications
The following table provides time code specifications for the NV5128 Multi-Format Router:
Machine Control Specifications
The following table provides port machine specifications for the NV5128 Multi-Format Router:
Specification Detail
Time code reference input Type: 1 BNC, 1 Phoenix.
Standard: SMPTE 12M.
Connector: BNC terminating, Phoenix.
Data Rates: 1/30th to 80 times normal.
Impedance: 75 Ω or 110 Ω.
Time code inputs and outputs Type: longitudinal time code.
Standard: SMPTE 12M.
Connector: Phoenix.
Data Rates: 1/30th to 100 times normal.
Impedance: 600 Ω or Hi-Z (> 20 kΩ), not selectable.
Input Level: 100 mV to 10 Vpp.
Output Level: 2.0 Vpp.
Specification Detail
Machine control inputs and
outputs
Type: bidirectional, dynamically configured.
Standard: RS-422 (Optional RS-232), ANSI/SMPTE 207M.
Connector: RJ-45.
Data rates: up to 115.2 kb/s.
